Lunawood Thermowood
LUNAWOOD THERMOWOOD is a beautiful, sustainable wood material produced by using natural methods, heat and steam. Thermal modification improves the wood’s properties, thereby expanding the range of applications in which the wood can be used. Thermowood is dimensionally stable, resistant to decay and resin free. It can be used inside or outdoors, in any climate. Lunawood is an non-toxic natural product which is easy to machine and install. Lunawood Thermowood is a sustainable and durable choice for facades, solar shades and other exterior applications as well as for interiors. Due the wood material is 100% resin free, Lunawood is also suitable for saunas.
Thermally modified timber has beautiful brown tone, which naturally weathers over time to beautiful silver-gray patina, if the wood is left untreated with pigmented and UV-protected wood oil.
See Lunawood Thermowood Guideline for Professionals for more information.
Thermowood Process
Studies on the possible benefits of thermal modification of wood began as early as the 1930s and 1940s in Europe and USA, but the manufacturing process never reached an industrial scale. Decades later, VTT (Technical Research Institute of Finland) became interested in the idea and as a result, the Thermowood process was patented and the brand was launched in Finland at the end of the 1990s.
Proficiency for premium quality
Our mills in Finland transform the very best Nordic Pine and Spruce into beautiful and long-lasting Lunawood Thermowood®. The patented production process is based on the gradual thermal modification of the wood, wherein the chemical and physical properties undergo a permanent change. Thermal treatment means that the process itself uses only water vapor and heat; no chemicals are being used. Heat inside the thermal modification chamber is slowly raised up to 212°C and the whole process can last up to 110 hours. Water is needed for two reasons: because the temperature rises so high, the water prevents the wood from burning during the thermo-treatment cycle. Water is also used to ensure the quality of the final product. Namely, the final moisture is added to the product to prevent cracking and ensuring long life. When the process is complete, the moisture percentage of the raw material is around 4 – 7 %.
Thermowood – certified quality
We produce trademarked Thermowood products by a patented and annually audited process. Our production process is audited three times a year by an external auditor. In addition, we carry out continuous quality control ourselves, as we take 10 samples of each furnace load and test them in our own laboratories in Iisalmi and Kaskinen. These test results are audited a couple of times a year by an external auditor.
Sustainability is the core of Lunawood Thermowood. Click and read more what does it mean.
The best raw materials
We use mainly Finnish PEFC-certified wood in our Thermowood production that is sorted in accordance with our specific and strict requirements. The high and even quality of our production is based of a logistics chain that is carefully managed from forest to final product. Together with our suppliers, select and use only the raw materials that are the best suited for our production in terms of type and quality.
Pine (Pinus Sylvestris)
Pine grown in the northern latitudes is our main raw material for Thermowood. We only use sound knotted wood to ensure the high quality of the final products. As a result, Lunawood is known for its top quality.
Spruce (Picea Abies)
The properties and quality requirements of the spruce that we use in production are similar to those of pine. Lunawood uses mainly spruce in the production of exterior cladding boards and other related products. In terms of production, knots are the main difference between pine and spruce: in spruce, the knots are smaller but relatively hard, which makes them break more easily during the processing.
Other species
The high quality of Lunawood Thermowood starts from the raw material. The main wood species modified are PEFC certified Scots pine and Norway spruce, which are graded in accordance with our specific and strict requirements. For Scots pine only sound knotted heartwood originated from top log is suitable for our products. The properties and quality requirements of the spruce that we use in production are similar to those of pine.
Good to know about Thermowood
The following will present some useful advice and recommendations on the use of Lunawood. The purpose of this information is to help you to enjoy all the many benefits of using Lunawood Thermowood.
See also the Lunawood Guideline for Professionals for more information.
- Durability
Durability
LunaThermo-D belonging to durability class 2 has a projected service life of 30+ years when resistance to decay is considered (BRE). This applies to exterior cladding, facade and decking applications. However the decking material is subject to surface-wear and loading which decreases the reasonable expected service life to 15–20 years. Thermowood is not recommended for use in direct contact with the ground.
- Equilibrium moisture content
Equilibrium moisture content
After the thermal process the equilibrium moisture content of Lunawood is 4–7%. In outdoor use (+20 Celsius, RH 85%) the equilibrium moisture content of LunaThermo-D pine stabilizes at 10% (EN 13183).
- Fastening by hand
Fastening by hand
Thermal processing makes wood slightly more susceptible to splitting. For this reason we recommend using self-tapping screws with a coarse thread or predrilled holes before fixing. The screws should be stainless steel and suitable for fastening wood. When using nails, they should not be closer than 7 cm from the end of the board or use pre-drilled nail holes. When using a conventional hammer, it is advisable to use a nail punch for the last 2–3 mm. Tongue and grooved boards should be fastened using pre-drilled holes from over the top of the tongue so that the screw or thin nail is driven in at an angle of less than 40 degrees. In the installation the using side is determined by the species: for Pine products use the heart side as using side and for Spruce product SAP (sapwood) as using side.
- Fastening – Gluing
Fastening – Gluing
Gluing of Lunawood Thermowood is possible. However the gluing and compression time may be 4–6 times longer compared to untreated wood. Always follow the glue manufacturers’ guidelines.
- Installation – Decking
Installation – Decking
When building a deck it is always recommended to keep the deck off the ground to improve the air circulation below. The gap between the boards should be at least 6 mm to secure air ventilation and promote drainage of rainwater. Any gap next to an adjoining wall should be at least 6 mm and the gap between two board ends should be 1-2 mm to allow for any movement. See the complete Lunawood Thermowood decking installation guide before installing.
- Installation – Cladding
Installation – Cladding
In claddings, ventilation should be provided behind the boards (min. 40 mm). Please also note that there should be at least 300 mm between the ground and lower edge of the cladding. Screws or nails can be used for mounting. They need to be stainless steel.
See the complete installation guide before installing.
- Machining – Milling
Machining – Milling
If Lunawood is intended to be milled, the blades should be in good and sharp condition to ensure good end results. The light, fine-grained saw dust is readily extracted with no adhesion to the cutter blades. Furthermore, due to the fine-grained sawdust, it is recommended to use a respiratory protection mask.
- Machining – Planing
Machining – Planing
Lunawood can be planed with a normal planer or planing machine. Planing Lunawood gives its surface a superior quality. The planing machine should be adjusted for hardwood species and the planing speed is less than with untreated similar wood. The raw material after thermal processing may be convex and therefore the feed rollers should be adjusted accordingly to prevent the boards from splitting.
- Machining – Sanding
Machining – Sanding
Sanding may not be needed with Lunawood at all because the quality of the surface is so good after being planed and milled. However, if Lunawood is sanded the resin free material keeps your sandpaper in good shape for a longer period of time.
- Machining – Sawing
Machining – Sawing
Sawing Lunawood is just as easy as sawing ordinary wood. However, the blade should be a sharp, fine-toothed saw and the wood should be fed slowly.
- Surface treatment – Outdoors
Surface treatment – Outdoors
Lunawood Thermowood should be surface treated before installation or immediately after installation if the beautiful brown color is to be retained. Treating the boards with tinted or pigmented wood oil, wax, wood-protecting stain, varnish or paint – which contains a UV-filter – can retain the brown surface color. The surface treatment can be applied either before or immediately after installation using only a thin coat. Any excess should be wiped off. However, one should always follow the manufacturer’s recommended guidelines.
- Surface treatment – Indoors
Surface treatment – Indoors
Normal paints, wood oils, waxes, and varnishes can be used indoors. For saunas, paraffin oil can be used in addition to a surface treatment agent to emphasize the color of Thermowood and protect it from impurities.
- The use of Lunawood without surface treatment
The use of Lunawood without surface treatment
Lunawood recommends surface treatment for Thermowood always when the end use application, such as facade, is exposed to weather. With all wood materials it is typical that after time fine cracks and splinters appear on the surface. Though Thermowood has lower potential for these defects, they still exist and coating protects the wood from them.
- Strength
Strength
Bending strength properties are somewhat reduced with heat treatment class LunaThermo-D. Therefore it is not recommended to use Lunawood in load bearing structures without additional support; or without strength calculations being carried out on a case-by-case basis.
- Termite Resistancy
Termite Resistancy
Lunawood is not termite resistant. Lunawood can be treated with specialist termite chemical treatments.
- Fire Rating
Fire Rating
Lunawood has D4 rating which means it same as any natural timber. Lunawood will accept standard fire
retardant treatments in the same way as un-modified timer. - Dimensions
Dimensions
Lunawood Thermally modified timber is available as standard in thicknesses 25, 32, 38, 50 mm
Standard widths 100, 125, 150, 175, 200 mm.
Planed finished sizes are slightly smaller than with unmodified wood.
Recommended planed dimensions are 19, 26, 32, & 42 mm thick and 92, 117, 140, 165, & 185 mm wide.
