CLADDING:
Lunawood cladding products should always be installed on support battens. Vertical battens (wood or metal) are spaced max. 600 mm centres. In vertical orientation, a double order of support battens is used to provide adequate air ventilation. The ventilation cavity should maintain a consistent minimum thickness of 25 mm to ensure drainage and ventilation. Lunawood ThermoWood® is not recommended to be installed in direct contact with the ground and thus sufficient ground clearance, based on the type of soil, is required. Stainless steel screws/nails are recommended.
The minimum thickness in facade profiles is 19 mm.
DECKING:
Lunawood decking profiles should always be installed on strong substructure. Double row of joists under the end points of the decking boards is recommended. Use spacing/insulation band to ensure capillary break between substructure and decking boards. Joist spacing for 26 mm thick decking boards is 450 mm. For 32 mm or thicker boards maximum joist spacing is 600 mm. The minimum thickness in decking profiles is 26 mm. Use Lunawood Profix hidden fixing to secure invisible fixing and 6mm gap between the boards. End-grain sealant is recommended.
For detailed information on fixings please refer to the Lunawood installation guide:
https://lunawood.com/download-centre
